【知識分享】保麗龍雕刻機操作的方法與步驟

來源：http://www.bnuj.com.cn 時間：2020-09-29

1、排好版面，包括設置材料高度、大小、距離、行距等參數。同樣內容的批量復制好。

1. First, arrange the layout, including setting the material height, size, distance, line spacing and other parameters. Copy the same content in batch.

2、然后設置走刀路徑（2D,3D,割），選刀時根據字體的大小，線粗細程度來選擇合適的刀具，走完路徑后看一下字有沒有沒走刀的地方，有的話證明刀具設置大了或修一下文字。

2. Then set the tool path (2D, 3D, cutting). Select the appropriate tool according to the size of the font and the thickness of the line. After the path is completed, check whether there is any place where the tool has not been moved. If so, it can be proved that the tool setting is large or the text is modified.

不同深度的文字要走不同深度的路徑，一般雕刻為2D選平底尖刀，切割割選直刀。為了加工出來的物品和設計的實際尺寸一致，更好提前設計一下刀具補償，路徑計算選擇計算內外輪廓，寬度為選擇刀具的一半，一般雕刻為內輪廓，切割為外輪廓，不保留原圖。

Different depth of text to take a different depth of path, generally carved for 2D flat bottomed sharp knife, cutting cut choose straight knife. In order to make the processed products consistent with the actual size of the design, it is better to design the tool compensation in advance, select the path calculation to calculate the internal and external contour, the width is half of the selected tool, generally carve as the inner contour, cut as the outer contour, without retaining the original drawing.

3、存儲雕刻路徑，不同深度的內容存儲不同的文件，例如一個版面內既有雕刻又有切割，因為雕刻深度或所選用的刀具不同，必須存為兩個路徑文件。存完雕刻路徑時必須刪掉雕刻路徑在作切割路徑并存儲路徑（注意次安裝完文泰需將此處的抬刀高度為３mm）。

3. The engraving path is stored. The contents of different depths are stored in different files. For example, there are both engraving and cutting in one layout. Because the engraving depth or the selected tool are different, two path files must be saved. When the engraving path is saved, the engraving path must be deleted and used as the cutting path and the path should be stored (note that the tool lifting height here should be 3mm after the first installation of Wentai).

4、打開運動管理系統。

4. Open the motion management system.

在自動點擊右鍵選折打并裝載打開在文泰中保存的要雕刻的路徑，換上所選的刀具，在手動中將雕刻頭移動到要雕刻的材料上定原點（在工作坐標X、Y、Z上點擊），切割時一般先把刀具移動到材料的前面把Z軸和臺面剛接觸到后把Z軸定0后，在抬起Z軸把刀具移動到材料的左下角把X,Y在定0即可。。。

Right click the right button to select, fold and load to open the path to be engraved saved in Wentai, replace the selected tool, and manually move the engraving head to the material to be carved and set the origin (click on the working coordinates x, y, z). When cutting, generally move the cutter to the front of the material, just contact the Z axis with the table top, set the Z axis to 0, and then lift the Z axis to move the tool to the material Set X and y at 0 in the lower left corner of the material...

假設同一版面上既有雕刻還有切割需要更換刀具時雕刻完成后卸下雕刻刀具，換上切割刀具只要把Z軸重新定原點即可，X、Y坐標一定不能更改，否則切割和雕刻跟排版版面不吻合。（切割時注意把進給速度調慢，不同材料在調整以下主軸轉速）。

Suppose that there are both engraving and cutting on the same layout, when the cutting tool needs to be replaced, the engraving tool will be removed after the engraving is completed, and the cutting tool can only be replaced by resetting the Z axis to the original point, and the X and Y coordinates must not be changed, otherwise the cutting and engraving are not consistent with the layout. (pay attention to slow down the feed speed when cutting, and adjust the spindle speed for different materials).

5、抬起主軸，移動龍門架到合適位置，加工完成。

5. Lift the spindle, move the gantry to the appropriate position, and finish the machining.

操作過程看似復雜難懂，其實1天就能學會(huì )，也要看個人的理解能力，這些都是雕刻機廠家服務范圍內的，詳情咨詢雕刻機代理商或雕刻機廠家。

The operation process seems complicated and difficult to understand. In fact, it can be learned in one day, which depends on the individual's understanding ability. These are within the service scope of engraving machine manufacturer. Please consult engraving machine agent or engraving machine manufacturer for details.

以上就會(huì )說小編所說的關于保麗龍雕刻機操作的方法與步驟，希望可以幫助到大家，如有疑問可關注公司網站：http://www.bnuj.com.cn會(huì )有在線客服與您進行解答。

The above will talk about the operation methods and steps of styrofoam carving machine mentioned by Xiaobian. I hope it can help you. If you have any questions, please pay attention to the company's website: http://www.bnuj.com.cn There will be online customer service to answer with you.
